DESCRIPTION

Basic Info.

Model NO.	DCP
Transport Package	Wooden Case
Specification	Standard
Trademark	Megajet
Origin	Beijing China
HS Code	8424200000
Production Capacity	50000 PCS Yearly

Product Description

20000psi High Pressure Water Hand Operated Dump Style Gun For Hydro Cutting
Introductions/Features:
DuraSafe 2,0000 psi hand-operated shut-in style control guns allow the operator to have complete control of the pressure at all times. Designed with safety, comfort,
and simplicity in mind, they are used for a variety of surface cleaning applica-tions and are available in two standard configurations.
• Shut-in style control guns do not dump water when the trigger is released. Useful in applications where excess water spillage and disposal are concerns. Use with
plunger style pumps such as the UNx ® requires the installation of a Shut-In regulator Valve
• 30-second field replaceable cartridge design for minimal downtime
• 48" distance from primary trigger to end of barrel to ensure maximum operator safety**
• Lightweight
• Special cam-operated trigger cuts required engagement force in half.
• DCPSi model features a fully adjustable body pad for maximum operator comfort in any position (shoulder, hip, chest, etc.)
• DCPxSi model includes an ergonomically designed shoulder stock.
• Adjustable secondary hand grip
• All pressure-bearing components are stainless steel
• Includes coupling to attach 1/4" NPT Male nozzles

How to choose a right HP Gun:
1. Confirm the Max. working pressure.
2. Confirm the Max. water flow.
3. Confirm the gun's type.

Replacement Cartridge:
All 20,000 psi DuraSafe Dump Style Control Guns utilize the C-20 cartridge, to completely rebuild the dump valve in about 30 seconds!
Basic Specifications:

Model	Trigger Actuation	Rest Type	Inlet Connection	Outlet Connection	Length		Weight		Max. Operation Pressure
					in	cm	lb	kg	psi	bar
DCP-20	Single	Body Pad	20K Port Male	9/16˝ MP Male	71	180	12.3	5.6	20,000	1,379
DCPX-20	Single	Shoulder Stock	20K Port Male	9/16˝ MP Male	66	167	11.4	5.2	20,000	1,379
DCP-20DD	Dual	Body Pad	20K Port Male	9/16˝ MP Male	75	190	16.7	7.6	20,000	1,379
DCPX-20D	Dual	Shoulder Stock	20K Port Male	9/16˝ MP Male	70	177	15.8	7.2	20,000	1,379

Spare Parts List:

ITEM PART NO. DESCRIPTIONS
1 26061 Coupling
2 J55620 Handle Assembly
2a J55614 Handle
2b J55617 Trigger Assembly
2c 26116 Pin
3 26689 Capscrew
4 52645 DCPSi-20 Body Assembly
54450 DCPxSi-20 Body Assembly
5 52635 CPSi-20 Cartridge
6 52543 Cartridge Plug
7 53304 Body Pad (DCPSi-20)
8 25296 Nut (DCPSi-20)
9 53303 Stud (DCPSi-20)
10 50127 Extension (DCPxSi-20)
11 50124 Shoulder Stock (DCPxSi-20)
